Name: 55inch Capacitive Touch Screen Kiosk 1920x1080 Resolution
Brand: Shenzhen TopAdkiosk Display Technology Co., Ltd.
Price: 1,525.00 USD
Availability: InStock

홈 제품 소개 디지털 간판 키오스크

55inch Capacitive Touch Screen Kiosk 1920x1080 Resolution

제품 상세 정보:

결제 및 배송 조건:

Minimum Order Quantity:	1

접촉

상세 제품 설명

Screen Size:	55 inch	Screen Resolution:	1920*1080
Brightness:	400CD/M²	Response Time:	6.5ms
Contrast Ratio:	4000:1	View Angle:	178°/178°(H/V)
System RAM:	DDR3 2GB	System ROM:	NAND FLASH 8GB
Decoding Resolution:	1080P	Power Input:	DC 12V/5A
Power Consumption:	≤5W (without peripherals)	Operating Temperature:	0°C to 40°C
Storage Temperature:	-20°C to 60°C	Humidity Range:	20%-80% RH at 40°C
Touch Points:	2/4/6 points
강조하다:	55inch capacitive touch screen kiosk , digital signage kiosk with 1920x1080 resolution , large touch screen kiosk with warranty

55-inch Capacitive Touch Screen Kiosk

Key Features:

High-resolution 55-inch capacitive touch screen
Multiple version options: USB, Network, PC, and Android configurations
Full HD 1080P display with industrial-grade LCD panel
Robust construction with cold rolled steel and toughened glass
Support for multiple media formats and playback modes
Network connectivity options including WiFi and 3G

USB Version Advertising Player

CPU	HD video and audio decoder chip
System RAM	DDR 128MB
System ROM	NAND FLASH 4G
Storage	SD/USB
Decoding resolution	MAX. 1080P
O/S	UCOS
USB 2.0 Port	1 x USB Host, 1 x USB OTG
Serial Port	1 x Serial Port
I2C Interface	1 x I2C Interface
LVDS Interface	1 x can directly drive 15 ~ 100 inch LCD screen, 50/60Hz
Audio Out	1 x Stereo Audio Out (2 x 10W/8Ω speaker can drive directly)
PWR Input	DC 12V/5A (Power On/Off)
PWR Consumption	Not more than 5W (Without speaker,LCD,backlight Inverter,USB device)
Shell material	Cold rolled steel with Aluminium edge
Glass	Toughened glass surface
Painting	Powder coating
Color	Black/silver/white etc.

Network Version Advertising Player

Main Hardware

Board configuration	CPU dual core ARM Cortex A9 1.5 GHz(max1.6GHz), Motherboard M158, GPU quad core ARM Mali-400 MP, HYNIX/SAMSUNG DDR3 1Gbyte, HYNIX/SAMSUNG NAND FLASH 8GB (Scalable TF/USB)
Decoding resolution	Perfect support 1080P Full HD

Main Function

OS	Android 4.2.2
Programming	Perfect support for video / picture / caption / logo / Date Time Day / weather, etc. regional free split-screen combinations; support background images
Play Mode	Receiving media content over the network, stored in the local loop after, commercials, broadcast regularly, gaskets playback; By U-import; U disk playback.

PC Version Kiosk (Touch Screen Optional)

Standard PC Specification

CPU	Intel G3260/3.2GHZ/Dual core
Main board	H81/B75
RAM	DDR3,2GB
HDD	S-ATAII 500GB/16MB/5400rpm
Graphics	Intel HD Graphics
Ports	4 x USB, 1 x VGA, 1 x LAN, 1 x AUDIO-OUT, 1 x MIC-IN,DVI,HDMI
Operating system	Windows7,windows8,windows XP,Linux,Apple etc.
