Screen Size: | 55inch | Screen Type: | Capacitive |
---|---|---|---|
Resolution: | 1920*1080 | Brightness: | 400CD/M² |
Response Time: | 6.5ms | Contrast Ratio: | 4000:1 |
View Angle: | 178°/178°(H/V) | System RAM: | DDR 128MB |
System ROM: | NAND FLASH 4G | Decoding Resolution: | 1080P |
Power Input: | DC 12V/5A | Power Consumption: | ≤5W |
Shell Material: | Cold rolled steel | Glass Type: | Toughened glass |
Operating Temperature: | +5°C ~ +50°C | ||
강조하다: | 55 inch touch screen kiosk,double sided digital signage kiosk,1920x1080 resolution touch kiosk |
Component | Specification |
---|---|
CPU | HD video and audio decoder chip |
System RAM | DDR 128MB |
System ROM | NAND FLASH 4G |
Storage | SD/USB |
Decoding resolution | MAX. 1080P |
O/S | UCOS |
USB 2.0 Port | 1 x USB Host, 1 x USB OTG |
Serial Port | 1 x Serial Port |
I2C Interface | 1 x I2C Interface |
LVDS Interface | 1 x can directly drive 15 ~ 100 inch LCD screen, 50/60Hz |
Audio Out | 1 x Stereo Audio Out (2 x 10W/8Ω speaker can drive directly) |
Power Input | DC 12V/5A (Power On/Off) |
Power Consumption | Not more than 5W (Without speaker, LCD, backlight Inverter, USB device) |
Component | Specification |
---|---|
Board Configuration | CPU dual core ARM Cortex A9 1.5 GHz(max1.6GHz), Motherboard M158, GPU quad core ARM Mali-400 MP, HYNIX/SAMSUNG DDR3 1Gbyte, HYNIX/SAMSUNG NAND FLASH 8GB (Scalable TF/USB) |
Decoding Resolution | Perfect support 1080P Full HD |
OS | Android 4.2.2 |
Programming | Support for video/picture/caption/logo/Date Time Day/weather regional free split-screen combinations; support background images |
Play Mode | Receiving media content over the network, stored in the local loop after, commercials, broadcast regularly, gaskets playback; By U-import; U disk playback |
Component | Standard Specification | High Specification (Optional) |
---|---|---|
CPU | Intel G3260/3.2GHZ/Dual core | Intel I3/4150/dual core,3.5GHZ Intel I5 4590/quad core3.4GHZ Intel I7-4790/quad core,3.6GHZ |
Main Board | H81/B75 | Asus P8 H81M-D |
RAM | DDR3,2GB | 4GB/8GB/16GB |
Storage | S-ATAII 500GB/16MB/5400rpm | 1TB HDD or 32GB/64GB/128GB/500GB SSD |
Graphics | Intel HD Graphics | HD5450,1GB; 2GB |
Ports | 4 x USB, 1 x VGA, 1 x LAN, 1 x AUDIO-OUT, 1 x MIC-IN,DVI,HDMI | Same as standard with additional options |
Operating System | Windows7,windows8,windows XP,Linux,Apple etc. | Same as standard with additional options |
Component | Specification |
---|---|
Kiosk Shell Material | 1.5mm cold rolled steel+Acrylic cover/Tempered glass |
Color | Silver /Black/White/customized pantone colors |
Wall Mounted Support | With wall mounted Support |
Audio | 2 x 10W Speakers, 1 x 30W Amplifier |
Ports | Power input | Power switch | PC switch | USB | LAN | WIFI |
Power Supply | International 110-240 AC power |
Operating Temp | Temperature: +5°C ~ +50°C | Humidity: 0% ~ 80% |
Packing Method | Export wooden box+export carton box+4cm foamy |
